xTool P3 80W CO₂ Laser Cutter with Intelligent Automation

The xTool P3 is a flagship 80W CO₂ laser cutter and engraver built for professional workshops, growing businesses and high-volume production. It combines industrial-level cutting power with a large working area, automated focusing and positioning, intelligent height adjustment and advanced safety features.

Unlike diode lasers, the P3’s CO₂ laser can cut and engrave clear acrylic. It can also process wood, leather, paper, cardboard, fabric, rubber, glass and many other non-metal materials. Its 80W output delivers cleaner, faster cuts with reduced charring, making it suitable for signage, displays, furniture components, packaging, personalised gifts and commercial production.

Powerful cutting performance:

• Cuts basswood up to 20mm under suitable conditions

• Cuts acrylic up to 25mm under suitable conditions

• Cuts clear, coloured and opaque acrylic

• Engraves glass and other compatible transparent materials

• Produces clean cuts across wood, leather, fabric and craft materials

Key features:

• Powerful 80W CO₂ laser

• Large 915 × 458mm working area

• Maximum processing speed of 1,200mm/s

• Automated Creation System for simplified setup

• Dual-camera positioning system

• 16MP panoramic SkyView camera

• Close-range detail camera for fine positioning

• Automatic LiDAR focusing

• Built-in motorised AutoLift Base

• Processes objects up to 220mm high

• Built-in inverter water chiller

• Integrated active fire-suppression system

• Certified Class 1 laser-safety design

• Long-life CO₂ laser tube rated for up to 10,000 hours under xTool laboratory conditions

• Compatible with xTool Studio

• Suitable for detailed one-off work and batch production

Automated workflow:

The P3 combines camera positioning, LiDAR measurement, autofocus and automatic bed-height adjustment. Place the material inside the machine, position the design using the live preview and allow the machine to configure the working height and focus automatically.

Safety features:

• Certified Class 1 laser-safety system

• Enclosed processing area

• Eight infrared sensors

• Temperature monitoring

• Side-camera monitoring

• Integrated active fire suppression

• Automatic safety detection

• Emergency-stop control

Suitable applications:

• Large acrylic signs and displays

• Clear-acrylic cutting and engraving

• Wooden signage and décor

• Packaging and product displays

• Leather products and patches

• Glass engraving

• Furniture and interior-design components

• Wedding and event products

• Commercial batch production

• Personalised gifts and promotional products

Specifications:

• Laser type: CO₂ laser

• Laser power: 80W

• Working area: 915 × 458mm

• Maximum speed: 1,200mm/s

• Maximum object height: 220mm

• AutoLift Base capacity: Up to 16kg

• Software: xTool Studio

• Safety classification: Class 1

Please note: The 5W IR laser module, RA3 rotary attachment, Intelligent Conveyor Feeder, AP2 Max air purifier, mobile stand and other accessories are sold separately unless specifically included in the selected package. The standard P3 uses an 80W CO₂ laser and does not include the optional IR module. Cutting performance varies according to material composition, thickness and selected settings.
